4 tons excavator rubber track undercarriage with slewing bearing

  Product description

1.
 ISO9001 quality certificate
2. Complete with steel track, track link , final drive, hydraulic motors, rollers, crossbeam
3. Drawings are welcome.
4. Loading capacity can be from 0.5T to 150T
5. We can supply both rubber track undercarriage and steel track undercarriage.
6. we can custom undercarriage from customers’ requestion.
We can recommend and assemble the suitable motor & drive equipment as customers’ request. We can design the whole undercarriage according to special requirement, such as measurements, carrying capacity, climbing etc. which facilitate the customers’ installation successfully.

4 tons excavator undercarriage with slewing bearing

Standard specification





Technical parameters


Type Parameters(mm) Track Varieties Bearing(Kg)
A B C D E
SJ050 1200 900 900 150 300 rubber track 500
SJ080 1240 940 900 180 300 rubber track 800
SJ100 1380 1080 1000 180 320 rubber track 1000
SJ150 1550 1240 1000 200 350 rubber track 1300-1500
SJ200 1850 1490 1300 250 400 rubber track 1500-2000
SJ250 1930 1570 1300 250 450 rubber track 2000-2500
SJ300A 2030 1500 1600 300 480 rubber track 3000-4000
SJ300B 1895 1500 1700 300 485 steel track 3000-4000
SJ400A 2166 1636 1750 300 520 rubber track 4000-5000
SJ400B 1990 1600 1800 300 530 steel track 4000-5000
SJ500A 2250 1720 1800 300 535 rubber track 5000-6000
SJ500B 2118 1591 1800 300 550 steel track 5000-6000
SJ700A 2812 2282 1850 350 580 rubber track 6000-7000
SJ700B 2795 2265 1800 350 600 steel track 6000-7000
SJ800A 2880 2350 1850 400 580 rubber track 7000-8000
SJ800B 2880 2350 1850 400 600 steel track 7000-8000
SJ1000A 3500 3202 2200 400 650 rubber track 9000-10000
SJ1000B 3500 3202 2200 400 670 steel track 9000-10000
SJ1500A 3800 3802 2200 500 700 rubber track 13000-15000
SJ1500B 3800 3802 2200 400 700 steel track 13000-15000
SJ2000B 3805 3300 2200 500 720 steel track 18000-20000
SJ2500B 4139 3400 2200 500 730 steel track 22000-25000
SJ3500B 4000 3280 2200 500 750 steel track 30000-40000
SJ4500B 4000 3300 2200 500 830 steel track 40000-50000
SJ6000B 4500 3800 2200 500 950 steel track 50000-60000
SJ8000B 5000 4300 2300 600 1000 steel track 80000-90000
SJ10000B 5500 4800 2300 600 1100 steel track 100000-110000
SJ12000B 5500 4800 2400 700 1200 steel track 120000-130000
SJ15000 6000 5300 2400 900 1400 steel track 140000-150000



The characteristics of construction rubber track undercarriage


1.  High cost.
2.  Heavy weight,big load capacity.
3. Drive device,big load capacity equipment generally is composed of hydraulic motor,gear-box,brake, valve bank .small volume,heavy weight,big driving force,and two rubber tracks can turn at the same time, and the turning radius is small.
4. Rubber track is special for construction machinery,there are many  kinds models in market,different load capacity use different pitch.Construction rubber track is thicker than agricultural rubber track,Wear-resisting, good tensile strength, can walk in complex conditions.
5. Wheel roller in good-seal, free maintenance in life, high machining accuracy, good cooperation, durable use.
6. Tension device is composed of oil cylinder,spring and other parts.By injecting butter into the cylinder, the shaft can reach the purpose of tightening, which has a cushioning effect. It has a small impact on the parts, and it is not easy to remove.
7. Truck frame is strong,heavy weight,big load capacity,good impact resistance.
